Fusion 3 Table Saw \ Replacement Parts Table \
64
© 2020 Laguna Tools
Key
Part No.
Description
Specifications
Qty
.2
924916-000
Front Rail Assembly
36"
1
.3
924917-000
Front Rail Bracket
36"
1
2
924783-000
Rear Rail (L)
1
3
924768-000
Front Rail (L)
1
4
924772-000
Front Rail Bracket (L)
1
6
924773-000
Right Table Assembly
1
.1
440098-000
Right Table
1
.2
173139-902
Brace
4
.3
230086-901
Tapping Screw
8
7
924969-901
Connect Plate
1
8
924796-000
Rear Table Leg Assembly
1
.1
924797-000
Rear Table Leg Assembly
1
.1
008308-100
Lock Nut
M10-1.5 (17Bx12H)
4
.2
000004-112
Hex Screw
M10-1.5x45
4
.3
049201-101
Hex Screw w/Flat Washer
M8-1.25x16 (13Bx6.5H)
3
.5
174780-308
Support Plate
1
.6
001102-505
Round Hear Tapping Screw
M4-1.59x16
16
.7
440099-000
Rear Table
1
.8
171301-904
Fixed Plate
4
.2
924798-000
Leg Assembly
1
.1
190208-365
Leg
2
.2
008006-100
Hex Nut
M8-1.25 (13Bx6.5H)
2
.3
230041-000
Leveling foot
S20C+NBR
2
9
000704-102
Flat Head Hex. Screw
M8-1.25x25
5
10
049201-102
Hex Screw w/Flat Washer
M8-1.25x12 (13Bx5.5H)
7
11
006305-100
Spring Washer
8.2x15.4
3
12
001803-103
CAP Screw w/ Spring Washer
M8-1.25x25/8.2x13.7
7
13
006001-049
Flat Washer
8.5x16x2.0
16
14
008006-100
Hex Nut
M8-1.25 (13Bx6.5H)
14
15
000003-105
Hex Screw
M8-1.25x25
2
127B
924970-000
52" Rail. Right Table. Rear
Table Assembly
1
