Fusion 3 Table Saw \ Replacement Parts Table \
© 2020 Laguna Tools
65
Key
Part No.
Description
Specifications
Qty
1
924971-000
52" Rail. Right Table. Rear
Table Assembly
52"
1
.1
924924-000
Rear Rail
52"
1
.2
924920-000
Front Rail Assembly
52"
1
.3
924921-000
Front Rail Bracket
52"
1
2
924783-000
Rear Rail (L)
1
3
924768-000
Front Rail (L)
1
4
924772-000
Front Rail Bracket (L)
1
6
924809-000
Right Table Assembly
1
.1
001803-102
CAP Screw w/ Spring Washer
M8-1.25x20/8.2x15.4
4
.2
006001-049
Flat Washer
8.5x16x2.0
8
.3
008006-100
Hex Nut
M8-1.25 (13Bx6.5H)
10
.4
000704-102
Flat Head Hex Screw
M8-1.25x25
4
.5
230041-000
Leveling foot
2
.7
440077-000
Right Table
1
.8
173139-902
Brace
4
.9
230086-901
Tapping Screw
8
.10
190205-308
Leg
2
7
924969-000
Connect Plate
1
8
924796-000
Rear Table Leg Assembly
1
.1
924797-000
Rear Table Leg Assembly
1
.1
008308-100
Lock Nut
M10-1.5 (17Bx12H)
4
.2
000004-112
Hex Screw
M10-1.5x45
4
.3
049201-101
Hex Screw w/Flat Washer
M8-1.25x16 (13Bx6.5H)
3
.5
174780-308
Support Plate
1
.6
001102-505
Round Hear Tapping Screw
M4-1.59x16
16
.7
440099-000
Rear Table
1
.8
171301-904
Fixed Plate
4
.2
924798-000
Leg Assembly
1
.1
190208-365
Leg
2
.2
008006-100
Hex Nut
M8-1.25 (13Bx6.5H)
2
.3
230041-000
Leveling foot
S20C+NBR
2
10
000704-102
Flat Head Hex Screw
M8-1.25x25
3
