Drive belt/s
The drive belt should last for many years [depending on the usage] but needs
to be inspected regularly for cracks, cuts and general wear. If damage is found,
replace the belt. If your machine is a 2-belt system, then both belts must be
replaced at the same time, as they are a matched pair. Never change only one
belt as this could cause vibration.
Replacing the drive belt(s)
To replace the belt/s you will have to remove the lower wheel.
1. Remove the allen screw that clamps the wheel to the axel.
2. Using a gear puller remove the lower wheel. Take care not to damage
the clamp screw thread.
3. Replace the drive belts.
4. Refit the lower wheel and re-clamp with the allen screw.
It is better to replace the drive belt/s early than to have a breakdown during an
important job.
Table insert
The table insert [throat plate] is made of plastic and is designed not to damage
the blade should they come in contact. If the blade slot becomes too wide or
the insert becomes damaged by the blade, it should be replaced. The
replacement insert will have to be fitted to the table hole, and you will have to
sand the sides. You will also have to cut the blade slot, and this should be done
prior to sanding the sides as the insert could spring and change size. The table
is provided with 4 jacking screws that can be adjusted so that the insert is level
with the top of the table.
Bearings
All bearings are sealed for life and do not require any maintenance. If a bearing
becomes faulty, replace it.
