laguna LT18 - Bandsaw LT 16 X 16

64
Bandsaw LT 16 X 16
Drawing
N°
MACHINE
CODE
Part description
1
16-16
5020081
Upper fly wheel
2
16-16
3205040
Ball bearing
3
16-16
5210030
Spacer
4
16-16
3205040
Ball bearing
5
16-16
Washer UNI6593 ZNT M10 11x30x2,5
6
16-16
Seeger D=52 (hole)
7
16-16
5150089
Upper door
8
16-16
5050063
Shaft upper wheel
9
16-16
Screw TCEI 8.8 UNI5931 M10x20
10
16-16
Screw STEI UNI5927 M10x35
11
16-16
5030010
Sliding support upper wheel ( Group with #20)
12
16-16
3262009
Thrust bearing ( Group with #14 )
13
16-16
5120036
Tension blade steel plate
14
16-16
3261009
Thrust bearing ( Group with #12 )
15
16-16
3402081
Handle for inclination
16
16-16
3401501
Block for inclination handle
17
16-16
3458001
Wheel rubber cover
18
16-16
3177002
Steel wire for tension blade indication
19
16-16
Frame
20
16-16
5030011
Support sliding part ( Group with #11 )
21
16-16
5120034
Tension cable stop
22
16-16
Seeger D=30 (shaft)
23
16-16
5051111
Rack support blade protection
24
16-16
3402080
Handle locking rack
25
16-16
5120500
Blade protection
26
16-16
5250020
Support of blade protection
27
16-16
Screw TCEI 8.8 UNI5931 M6X16
28
16-16
Screw TSPEI 10.9 UNI5933 M6X16
30
16-16
Nut UNI5588 PG ZNT M12
31
16-16
Washer M12 12,5x28x3
34
16-16
5080002
Tensioning blade screw
35
16-16
5270011
Spring steel blade protection
36
16-16
5031032
Parallel fence
37
16-16
5051250
Special nut
38
16-16
5060011
Spacer ( Group with part #48 )
39
16-16
5400608
Table level register
40
16-16
5120027
Fence locking plate
41
16-16
Fixing pin ( included #42)
42
16-16
3410640
Hand-wheel for upper wheel rise and fall
43
16-16
3401270
Upper door closing handle
44
16-16
Screw TE 8.8 UNI5739 M12x60
45
16-16
5140001
Tension blade spring
46
16-16
7100900
Tension blade indication box
47
16-16
5030044
Support of parallel fence ( included #56 )
48
16-16
5400501
Round bar support fence ( included #38 )
49
16-16
included #50,51,52,53,54,55
50
16-16
5320150
Connection box ( included #49,51,52,53,54,55 )
51
16-16
3450001
Included #50,49,52,53,54,55
52
16-16
Included #49,50,51,53,54,55
