POWER INLET/MAINS SWITCH
The power inlet is a standard IEC inlet socket with a mains power switch, located at the rear of the
machine. There is a main power fuse internal in this IEC socket. The fuse should be a M205, 250VAC,
8A.
POWER SUPPLY
The machine is powered by a 600W 12V power supply. AC input is universal 85-265VAC 47-63Hz.
LAMPS
All button lamps are 12VDC T10 LED or equivalent.
All Playfield tile lights are FB205 PCBs.
All remaining lighting is RGB LED strip.
Contact your nearest LAI Games office for replacement LED strip to ensure color is matched.
MAINTENANCE
EXTERIOR
• Regularly dust and clean the external cabinet areas as required, using a soft water-damp
cloth and mild soap.
• Check for blown bulbs and replace as required.
• Check all LED strips are functioning and repair as required.
• Check that all playfield tiles are operating and positioned correctly. Tiles should all be at the
same level, orientation, and spacing.
• Check all foam padding on the playfield cross-beam mounts is intact with no exposed metal.
Re-glue any foam that has come loose
• Check below the playfield for stuck balls, clear out any obstructions to allow balls to roll
freely.
INTERIOR
• Regularly dust and vacuum the interior of the cabinet, taking care to remove any objects
that may have fallen.
• Check and tighten all fixing hardware and fasteners as required.
• Check the ball dispenser sensors are clear, blow out any dust from the optical sensors.
• Check the ball lifter is free to rotate and balls are free from obstruction.
• Check the balls are clean and undamaged. Discard any balls that are cracked or deformed.
