SECTION B: TECHNICAL DETAILS
POWER SUPPLY
The universal AC input power supplies generates 12VDC for the entire machine. The power supply
output voltage should be 12VDC. It can be adjusted when necessary by turning the blue adjustment
trimpot with a small Philips screwdriver.
WARNING: Always turn OFF mains power and unplug the game before cleaning the interior
of the machine.
Always after cleaning the cabinet interior, check all harness connectors and restore all loose or
interrupted connections.
WARNING: It is advised that anybody using SECTION B for repairing or modifying any of the
components of the game should be a qualified technician, having at least a
basic knowledge of digital components, integrated circuits and electricity.
