Lake Shore Model 330 Autotuning Temperature Controller User’s Manual
4-10 Remote Operation
4.3 IEEE-488/SERIAL INTERFACE COMMAND SUMMARY
The IEEE-488/Serial Interface commands are listed alphabetically in function order. There are five command
groups: Common Commands (Paragraph 4.3.2), Interface Commands (Paragraph 4.3.3), Display Commands
(Paragraph 4.3.4), Control Process Commands (Paragraph 4.3.5), and Curve Commands (Paragraph 4.3.6).
The commands are listed in the same order as shown below.
Command Function Page
Common Commands
*CLS Clear Interface .................................... 4-11
*ESE Set Std. Event Status Enable ............. 4-11
*ESE? Query Std. Event Status Enable......... 4-11
*ESR? Query Std. Event Status Register....... 4-11
*IDN? Query Identification............................. 4-11
*OPC Set Operation Complete ..................... 4-11
*OPC? Query Operation Complete................. 4-11
*RST Reset Instrument ................................ 4-12
*SRE Set Service Request Enable............... 4-12
*SRE? Query Service Request Enable .......... 4-12
*STB? Query Status Byte............................... 4-12
*TST? Query Self-Test................................... 4-12
*WAI Wait-To-Continue ............................... 4-12
Interface Commands
ADDR Set Address ........................................ 4-13
ADDR? Address Query.................................... 4-13
END EOI ..................................................... 4-13
END? EOI Query........................................... 4-13
MODE Remote Mode ..................................... 4-13
MODE? Remote Mode Query .......................... 4-13
TERM Terminator .......................................... 4-13
TERM? Terminator Query................................ 4-14
Display Commands
CCHN Set Control Channel ........................... 4-14
CCHN? Control Channel Query....................... 4-14
CDAT? Control Sensor Data Query ................ 4-14
CUNI Set Control Units ................................ 4-14
CUNI? Control Units Query ............................ 4-14
FILT Set Display Filter ................................ 4-15
FILT? Display Filter Query ............................ 4-15
SCHN Set Sample Channel........................... 4-15
SCHN? Sample Channel Query ...................... 4-15
SDAT? Sample Sensor Data Query................ 4-15
SUNI Set Sample Units................................ 4-15
SUNI? Sample Units Query............................ 4-15
Command Function Page
Control Process Commands
CLIM Control Limit ......................................4-16
CLIM? Control Limit Query............................4-16
GAIN Set Gain ............................................4-16
GAIN? Gain Query ........................................4-16
HEAT? Heater Query.....................................4-16
RAMP Enable/Disable Ramping...................4-16
RAMP? Ramping Enable/Disable Query ........4-16
RAMPR Set Ramp Rate in K/min....................4-17
RAMPR? Ramp Rate Query..............................4-17
RAMPS? Ramping Status Query ......................4-17
RANG Set Range .........................................4-17
RANG? Range Query .....................................4-17
RATE Set Rate ............................................4-17
RATE? Rate Query ........................................4-17
RSET Set Reset...........................................4-17
RSET? Reset Query ......................................4-17
SETP Set Setpoint.......................................4-18
SETP? Setpoint Query...................................4-18
TUNE Tune Status .......................................4-18
TUNE? Tune Query........................................4-18
ZONE Store Zone.........................................4-18
ZONE? Zone Query........................................4-18
Curve Commands
ACOMP Set A Compensation .........................4-19
ACOMP? A Compensation Query .....................4-19
ACUR Set Curve for A ..................................4-19
ACUR? Curve A Query...................................4-19
ATYPE? A Input Type Query ...........................4-19
BCOMP Set B Compensation .........................4-19
BCOMP? B Compensation Query .....................4-19
BCUR Set Curve for B ..................................4-19
BCUR? Curve B Query...................................4-20
BTYPE? B Input Type Query ...........................4-20
CUID? Curve Identification Query.................4-20
CURV Curve Set...........................................4-20
CURV? Curve No. Information Query.............4-21
ECUR Edit Curve..........................................4-22
FREE? Curve Bytes Free Query....................4-22
KCUR Delete Curve......................................4-22
SCAL SoftCal Entry .....................................4-22
4.3.1 Command List Structure
Command Name
Brief Description of Function
Syntax of what user must input
CUNI?
Input:
Returned:
Remarks:
Control Units Query
CUNI?
K, C, V, R, or M
Used to query the unit for current control units
information. The character returned will be K for
kelvin, C for Celsius, V for Volts, R for Ohms, or
M for millivolts.
Information returned in response
to the query
Explanation and definition of
returned data
