Lake Shore Model 330 Autotuning Temperature Controller User’s Manual
5-4 Service & Calibration
5.5 OPTIONAL SERIAL INTERFACE CABLE AND ADAPTERS
To aid in Serial Interface troubleshooting, Figures 5-6 thru 5-8 show wiring information for the optional cable
assembly and the two mating adapters.
BLACK
RED
GREEN
YELLOW
RxD
Gnd
Gnd
TxD
12
3
4
56
12
345
6
Figure 5-6. Model 2001 RJ-11 Cable Assembly Wiring Details
13 12 11 10 9 8 7 6 5 4 3 2 1
25 24 23 22 21 20 19 18 17 16 15 14
= NOT USED
654321
DB25 CONNECTOR
RJ11
Receptacle
RxD
Gnd
TxD
For Customer-supplied
computer with DB-25
Serial Interface
Connector configured
as DCE. If the interface
is DTE, a Null Modem
Adapter is required to
exchange Transmit and
Receive lines.
Figure 5-7. Model 2002 RJ-11 to DB-25 Adapter Wiring Details
54321
9876
= NOT USED
654321
DB-9 CONNECTOR
RJ11
Receptacle
Gnd
RxD
TxD
For Customer-supplied
computer with DE-9
Serial Interface
Connector configured
as DTE. If the interface
is DCE, a Null Modem
Adapter is required to
exchange Transmit and
Receive lines.
Figure 5-8. Model 2003 RJ-11 to DE-9 Adapter Wiring Details
