Lake Shore Model 330 Autotuning Temperature Controller User’s Manual
6-4 Options and Accessories
Cable Length: 4.3 meters (14 feet)
C-330-U-6-1
Figure 6-1. Model 2001 RJ-11 Cable Assembly
43 mm
(1.69 inches)
15.8 mm
(0.63 inches)
55 mm ( 2.16 inches)
25
1
C-330-U-6-2.wmf
Figure 6-2. Model 2002 RJ-11 to DB-25 Adapter
60.3 mm (2.37 i nches)
15.9 mm
(0.63 inches)
32.5 mm
(1.28 inches)
9
1
C-330-U-6-3.emf
Figure 6-3. Model 2003 RJ-11 to DE-9 Adapter
