Appendix Switch and key combinations
on the VMS / FMS front panel
Action Switch Position Switch Position Buttons / Other
top selector switch (1) bottom selector switch (2)
_____________________________________________________________________________________________________
Recall correction ranges Status Monitoring display Acceptance
Automatic
Setting
Clear memory
Cold start (long reset) Status Fault / Switch 1 OPEN
Warm start (short reset) Status Fault / Switch 1 OPEN and
Switch 2 OPEN
Code entry for Status Parameterisation Switch 2 / 3 OPEN
parameterisation Switch 4 CLOSE
Scan fault history Status Monitoring display Channel 1 switch
Automatic OPEN or CLOSE
Setting (not in fault mode)
Clear memory
Recall correction Load rating Acceptance
input values
Load adjustable via Load rating Automatic Channel 1 switch open/ close
switch 1 (manual operation)
Quit manual mode Load rating Automatic operate a switch,
channel 2,3 or 4
Load adjustable via Load rating Setting Channel 1 switch
switch 1 (internal load default) OPEN or CLOSE
EG / ES mode Load rating Setting Channel 3 switch CLOSE
is activated Clear memory Mode GL or RG
(EI on display)
Compound engaged
(No "ES barred” message)
EG / ES mode Setting Switch on front panel
is terminated Clear memory operated in EG or ES mode
Exception Switch 1 at sep.
ignition point or load default
configured via switch
Display of running time Set-point value Monitoring display Acceptance
meter / Starts counter Automatic
Store point Set-point value Setting Acceptance
Actual value feedback
Clear present curve Set-point value Clear memory Acceptance
Display of acceptance data Set-point value Acceptance
CRCs for all levels feedback
Oil/gas safety times
Pre-ventilation time
Traverse channels Set-point value Setting Switch 1 - 4
Actual value feedback
Channel 5 set-point adjustable Channel 5 display Setting Switch 2
Scanning of serial No. Actual value feedback Monitoring display Acceptance
Automatic
Call up Actual value feedback Automatic Channel 3 switch up
flame intensity
126
