Settings List of Parameters
(Level 0 and 1 parameters only)
Para- Short Safety Lower Upper
meter- design- level limit limit Standard
No. nation Description values Aids
_____________________________________________________________________________________________________
Correction
433 K1 Spreiz 1 0 999 10 P22
434 K2 Spreiz 1 0 999 10 P22
517 KB11.1 0 0 999 0 P7
597 KB21.1 1 0 999 0 P7
Monitor output
677 Moni.1 1 0 23 0 P8
678 Moni.2 1 0 25 0 P9
679 Moni.3 1 0 25 0 P9
3
680 Moni.4 1 0 25 0 P9
4
681 Moni.5 1 0 25 0 P9
5
682 Moni.6 1 0 25 0 P9
6
683 Moni.7 1 0 25 0 P9
7
684 Moni.8 1 0 25 0 P9
8
685 Unt.Mo1 1 0 999 0 P10
686 Unt.Mo2 1 0 999 2: 0 P10
687 Unt.Mo3 1 0 999 3: 0 P10
688 Unt.Mo4 1 0 999 4: 0 P10
Spread factor for correction input
(00.0 99.9) 01.0 = no expansion
Spread factor for correction input
(00.0 99.9) 01.0 = no expansion
Correction range, correction input 1
Correction range, correction input 2
Definition of the monitor output
with curve set 1
0= internal load 14= channel 4 actual value
1= channel 1 setting 15= channel 5 actual value
2= channel 2 setting 21= external load
3= channel 3 setting 22= correction input 1
4= channel 4 setting 23= correction input 2
5= channel 5 setting 24=O -actual value
2
11= channel 1 actual value 25=O -setpoint
2
12= channel 2 actual value 26=Flame intensity
13= channel 3 actual value
Definition of the monitor output
with curve set 2
Definition of the monitor output
with curve set
Definition of the monitor output
with curve set
Definition of the monitor output
with curve set
Definition of the monitor output
with curve set
Definition of the monitor output
with curve set
Definition of the monitor output
with curve set
Monitor output, curve set 1:
4 mA correspond to X points
Monitor output, curve set
4 mA correspond to X points
Monitor output, curve set
4 mA correspond to X points
Monitor output, curve set
4 mA correspond to X points
