Appendix Safety Interlock Chain
Example safetz interlock chain 230 V
138
6
230 V contacts,
safety interlock circuit
230V
K1
K2
K1
9
+24V
FMS
A2
A2
K1
A1
A1
K2
N
K1 and K2 must be diversitary, with overlapping contacts
K2
35
Unlocking switch
