1.6 CONNECTION OF THE UNIT
A. Position the CO2 gas tank in the desired location. Assemble high pressure regulator to CO2
gas tank and run jumper line to low pressure regulator.
B. Attach the CO2 gas line to the carbonator by attaching the line from the high pressure regulator
to the single check valve marked “gas” on top of the carbonator tank. The setting of the high
pressure CO2 gas regulator should be 90 PSI (0.621 MPA) to 110 PSI (0.758 MPA).
5
WARNING DO NOT TURN ON THE CO2 SUPPLY AT THIS TIME.
ADVERTENCIA NO CONECTE TODAVÍA LA ALIMENTACIÓN DE CO2.
AVERTISSEMENT N’OUVREZ PAS L’ALIMENTATION EN CO2 À CE MOMENT.
C. Position the syrup pumps in the desired location. Attach the CO2 gas lines leading from the low
pressure regulator to these pumps.
D. Connect syrup lines from pumps to the appropriate inlets on the unit behind the splash plate.
The syrup inlets are identied.
E. Mount the water lter assembly (if used) and water regulator in a convenient location.
F. Connect water inlet line to water regulator, to water lter, and then to the water inlet of the
carbonator pump on the carbonator.
G. Provide a suitable drain in the plumbing system and attach the gray tube to it. The drip pan
drain outlet is located on the bottom of the driptray. Drain tubing is supplied with the unit.
H. Plug in the transformer box to a standard 20 AMP, 110 VAC single phase outlet. The unit will
internally convert the 110 VAC to 24 VAC.
1.7 START UP
A. After all connections to water, CO2 gas, electrical power, and syrup pumps are made, check for
leaks.
B. Be sure bag-in-box contains syrup.
!
CAUTION DO NOT OPERATE CARBONATOR PUMP WITH WATER SUPPLY SHUT OFF.
PRECAUCIÓN NO HAGA FUNCIONAR LA BOMBA CARBONATADOR CON SUMINISTRO DE AGUA CIERRE.
ATTENTION NE PAS FAIRE FONCTIONNER LA POMPE DE CARBONATEUR L’APPROVISIONNEMENT EN EAU
COUPÉE.
C. Turn on water; open the pressure relief valve on the carbonator tank by lifting the wire ring or
ipping lever, and hold it open until water ows from the relief valve. Close the relief valve and
turn on the CO2 gas and electrical power in that order.
D. To ll all lines with water, cycle the carbonator several times by operating the dispensing valves.
1. A low pressure gas regulator controls the ow of syrup to each dispensing valve. For
proper operation of the valves, the pressure regulator should be set so that 65 PSI is at the
shut-off of the valve.
