lancer MVU TOWER - Specifications

MVU TOWER SPECIFICATIONS
3
This unit emits a sound pressure level below 70 dB
DIMENSIONS
Width: 7.25 inches (184.15 mm)
Depth: 9 inches (228.6 mm)
Height: 16.5 inches (419 mm)
ELECTRICAL
24 VAC/ 60 Hz
FITTINGS
Plain water inlet: 3/8” barb
Brand syrup inlets: 3/8” barb
WEIGHT
Shipping: 15 lbs (7 kg)
PLAIN WATER SUPPLY
Min owing pressure:
20 PSI (0.138 MPA)
Max owing pressure:
50 PSI (0.345 MPA)
CARBON DIOXIDE (CO2)
Min pressure:
90 PSIG (0.621 MPA)
Max pressure:
110 PSIG (0.758 MPA)
