277
13) Position the jack under the car
near the wheel to be replaced in the
point shown on the panelling at
approximately 20 cm from the fend-
er edge, as shown in (fig. 12).
11) Place the bushing A (fig. 11)
for the wheel bolts on the ratchet
wrench B.
IMPORTANT The ratchet wrench
must be used on one side to unscrew
and on the other side to screw.
12) Loosen the wheel bolts by
about one turn, then rock the car to
make it easier to remove the rim
from the wheel hub.
Warn anyone nearby
that the car is about to be
lifted. They must stay
clear and not touch the car until
it is back on the ground.
fig. 12
L0A6026b
fig. 11
L0A0037b
