278
15) Insert the ratchet wrench A
(fig. 14) with the bolt bush B on the
jack groove.
IMPORTANT The ratchet wrench
must be used on one side to unscrew
and on the other side to screw.
16) Turn the jack handle and lift
the car until the tyre is a few cen-
timetres off the ground.
17) Loosen the wheel bolts and
remove the wheel.
IMPORTANT To make this opera-
tion easier, use the proper bolt bush
A (fig. 15).
18) Make sure the surfaces of the
spare wheel that come into contact
with the hub are clean and free from
any impurities which could result in
the wheel bolts working loose.
fig. 15
L0A0328b
fig. 13
L0A0040b
14) Turn the jack handle A
(fig. 13) by hand so to open it par-
tially and position the jack under the
car.
Turn the jack handle until the jack
groove B fits onto the bottom edge C
of the underbody correctly.
fig. 14
L0A0041b
