5K-MNL-GEM5000 GEM5000 Gas Analyzer
Impact/Total Pressure Port
Static Pressure Port
Figure 6 - Pitot Tube
Impact
Pressure/
“Low Pressure”
Static
Pressure /
“Low Pressure”
Static
Pressure /
“High Pressure”
Impact
Pressure/
“High Pressure”
Figure 7 - Orifice Plate (WellSide) Orifice Plate
Page 34 Copyright LANDTEC North America, Inc. V1.13
