Lantronix Maestro E220 Series User Manual

Services
E220 Series Cellular Router User Guide 190
Screen 12-5c: Data Send configuration – Static IP SIM
Screen 12-5d: Data Send configuration – Static IP SIM
Send Data Configuration
The data from RS485 port can be sent either via TCP or UDP using any of the available TCP
interfaces.
If a dynamic IP SIM is inserted in the Router, the router needs to be configured in client mode
sending data to an external (WAN) or internal (LAN) server
If a static IP SIM is inserted in the router, the router needs to be configured in server mode
listening either on an external WAN IP or an internal LAN IP
Content Filtering
Services > Content Filtering
