Services
E220 Series Cellular Router User Guide 189
Parameters Description
• 4800
• 2400
The default baud rate is 230400.
Data bit Select the number of data bits:
• 8
• 7
• 6
• 5
The default data rate is 8.
Parity A parity bit is added to the end of the string of binary code that
checks if the number of bits in the string with value one is even or
odd. They are used for detecting error.
Select the parity bit:
• Odd
• Even
• None
The default data rate is None.
Stop bit Select the number of stop bits:
• 1
• 2
The default stop bit is 1.
Mode Select the mode of serial communication:
• Transparent
Transparent mode of communication do not alter any data
structure before or during the data communication.
• Modbus RTU or Modbus TCP:
It converts the Modbus RTU data to/from RS485 to modbus
TCP before transmitting over TCP network.
Screen 12-5b: Data Send configuration – Dynamic IP SIM
