E220 Series Cellular Router User Guide 202
• $GPGGA,120133.0,1907.469671,N,07250.544473,E,1,05,1.0,43.1,M,-64.0,M,,*42
Parameters Description
MID GGA Parameters
MID GGA Protocol Header
Example – $GPGGA
UTC Time Time in hhmms.sss
Example – 120133.0
Latitude Latitude in ddmm.mmmm
Example – 1907.469671
N/S-Indicator N = North or S = South
Example – N
Longitude Longitude in ddmm.mmmm
Example – 07250.544473
E/W-Indicator E = East or W = West
Example – E
Position-Fix-Indicator Indicates
• 0 – Fix not available or invalid
• 1 – GPS SPS Mode, fix valid
• 2 – Differential GPS, SPS Mode, fix valid
• 3 to 5 – Not supported
• 6 – Dead Reckoning Mode, fix valid
Example – 1
Satellite-Used Number of satellite used to receive GPS signals.
The range for the number of satellite used is 0 to 12.
Example – 05
HDOP Horizontal Dilution of Precision
Example – 1.0
MSL Altitude Altitude in meters.
Example – 43.1 meters
Units Example – M meters
Geoid Seperation Geoid-to-ellipsoid separation.
Ellipsoid altitude = MSL Altitude + Geoid Separation
Example – -64.0 meters
Units Example – M meters
Age of Diff.Corr. Null fields when DGPS is not used.4
The units is sec.
Diff. Ref.Station ID -
Checksum *42
<CR><LF> End of message termination
Table 11.8-3: GGA Data Format
