E220 Series Cellular Router User Guide 42
B. WAN
Graph shows past three minutes average WAN and Cellular traffic and peak WAN and Cellular traffic
on the router.
Screen 8-6: Real Time WAN Traffic Graph
Parameters Description
Traffic (Inbound / Outbound) Graph shows the periodic average WAN and Cellular Traffic on the
Router.
Details
• X axis – Time Interval (1 minute)
• Y axis – WAN and Cellular Traffic (kB/s)
Legends
• Blue – Inbound Traffic
• Green – Outbound Traffic
Table 8.5-4: Real Time WAN Traffic Graph
