E. Wi-Fi
Graph shows past three minutes average Wi-Fi traffic and peak Wi-Fi traffic on the router.
Screen 8-9: Real Time Wi-Fi Traffic Graph
Parameters Description
Traffic (Inbound / Outbound) Graph shows the periodic average Wi-Fi Traffic on the Router.
Details
• X axis – Time Interval (1 minute)
• Y axis – Wi-Fi Traffic (kB/s)
Legends
• Blue – Inbound Traffic
• Green – Outbound Traffic
Table 8.5-7: Real Time Wi-Fi Traffic Graph
