LT-3100 User & Installation Manual Rev. 1.06 Serial Interface (RS-422)
Lars Thrane A/S www.thrane.eu Page 98 of 155
BAM sentences
The LT-3100 system supports connection to an external Central Alert Management (CAM) system via an RS-
422 interface from the LT-3100 system, as illustrated in Figure 135. The CAM system can receive BAM
information (e.g. warning and cautions) from the bridge equipment and centralize and present this
information to the user, which can be acknowledged to the BAM equipment (here the LT-3100 system).
Table 26 presents the supported BAM sentences by the LT-3100 system. The configuration of the BAM
sentences is illustrated and described in GNSS and BAM on page 124.
NOTE: The encoding of BAM sentences is defined in IEC 61162-1 (Edition 5.0, 2016-08), the
encoding is similar to NMEA 0183.
The BAM sentences and decoding of these are further documented in App. E - BAM Sentences on page 139.
