Missing line measurements
1
P1
2
Initialize
device for
vertical and
horizontal
values.
See "Level-
ling".
1
3
Aim laser at first
target.
4
2
5
Aim laser at second
target.
13.207m
6
i
Level the device
and further
values are
displayed !
Do not move
Smart Base
after levelling!
-1.697 m
2.419 m
35.06°
2.995m
Levelling
i
Level the device
to get more
measuring data.
Do not move
device after
levelling.
90°
90°
±5°
-1.697m
Rotate the device
two times clock-
wise 90°. Follow
the instructions on
the display. Level-
ling is finished when
OK icon appears
on the display.
For levelling,
Smart Base has
to be folded out
and device needs
to be in an incli-
nation range of
+/-5°.
Check status
line:
indicates proper levelling
indicates insufficient levelling
indicates that smart base was tilt-
ed and can affect measuring ac-
curacy
