Laser Technology TruPoint 300 - Sloped Objects

Laser Technology Inc. - TruPoint
™
300
34
ENFunctions
Sloped objects
1
2
3
Aim laser at upper
target point.
4
5
Aim laser at lower
target point.
11.00 °
-3.440 m
30.367 m
5.452 m
P2 distance
Vertical height be-
tween both points
P2 angle
Distance between
both points
6
-4.230 m
39.10 °
7
Use Up/Down
navigation keys
to show more
results.
Horizontal distance
between both points
Included angle
between both points
i
Indirect distance measuring between 2 points with addi-
tional results. Ideal for applications such as length and slope
of roof, height of chimneys,…
It is important, that the instrument is positioned in the
same vertical plane as the 2 measured points. The plane is
defined of the line between the 2 points. This means, that
the device on the tripod is only moved vertically and not
turned horizontally to reach both points.
