3.3.4 C200 parametre
Parameter:
HN
Default:
P1
Flushing Pulse, Water
Time for water should be
increased.
25
sec.
P2
Flushing Pulse, Air
Time for air, to be increased
with min, 30 sec.
45
sec.
P3
Blowing after prerinse
Time must be doubled?
4
min.
P4
Blowing after middle phases
Time must be doubled?
4
min.
P5
Blowing after final phase
Time must be doubled?
8
min.
P10
Temp. Limit, return water
Return Temperature shall be
decreased
40
°C
P11
Temp. Limit, outgoing water
Outgoing temperature shall be
increased.
82
°C
P15
Node address
Must be 75
75
-
P16
Versionsnumber
Software version 1.12 or newer
1.12
-
P17
Min. time circulation cleaning
Time must be doubled
15
min.
P22
External air injection delay
Individual adjustment
?
Sec.
P23
Extra flushing pulse air time (Trombone)
Individual adjustment
?
Sec.
P28
Acid/desinfection circulation (cleaning time)
15
Min.
P29
Pulse after blowing air time ON
Must not be 0, in order to dry
the HN.
10
Sec.
P30
Pulse after blowing air time OFF
Must not be 0, in order to dry
the HN.
10
Sec.
P50
Cleaning program
C200 timing for HN isadapted
for cleaningprogram 2
2
-
P54
Heater
Heater must be installed
1
-
P58
ALCOM-bus
C200 sends messages to HN
during cleaning.
1
-
3.3.5 AC and SC parameters
The AC has 3 parameters with influence on the cleaning process:
Regulator Block: (menu 217)
This parameter is set depending on whether there is a regulator block installed or not. If a
regulator block is installed, the shutoff valve is controlled by this, if not the MPE/MPC controls
the shutoff valve. If a regulator block is installed the value is set to ON, if not it is set to OFF.
Default value is OFF. (se Figure 3.)
