8.3 Serial interfaces RS232 / 485
RS232 / 485 Interface Module (order no. LRZ 913) with 9-pole SUB-D socket. Electrically isolated by
optocoupler. With the LAUDA instruction set essentially compatible to the Ecoline and Integral Series.
The RS232 interface can be connected directly to the PC with a 1:1 through-contact cable (order no.
EKS 037).
Interface description and commands see chapter 7.15.
8.3.1 Menu structure for RS232 / 485 Interface Module (Master)
All existing menu points are illustrated. However, the Master unit masks out menu points which cannot
be executed.
1%21
Actual bath temperature
or actual value of
external temperature
LMnet Configure
modules
RgmYW
Display level
@ 777
Select RS485 address
ac 77
Select baud rate
E 777
Select RS232 or 485
cDE
Restore factory settings
Dlc
Quit menu
pR--- Configure serial
module
TDp : Display module software
version
T13 : Display 24V supply
voltage
Rlp^G : Module serial number
Places 1-5
Dlc
Quit calibration level
Rlp^K : Module serial number
Places 6-10
