Proline Low-temperature Thermostats
YACE0072 / 21.08.07 Maintenance 115
9.2.4 Device data
Master
Æ LMDkt Æ RgmVW Ì Section 7.6.8
− Various device datas are displayed.
Command
Device data
Æ Settings Æ Device status Æ
Device data Æ Display
− T ext shows various actual temperatures
in °C from ext. Pt100 and the modules.
− T cont. head and T heatsink are
temperatures of electronics in the Master
in °C.
− Pump power in Watts, speed in rpm,
current in ampere (A).
− T
int
indicates the current internal bath
temperature in °C.
− Mains voltage in percentage (%) of
nominal and frequency in hertz (Hz).
− Level indicates the liquid level in the
internal bath.
− Voltage of power transformer, 5V supply
and fan in Volt.
− Cur. cons.: Mains current consumption in
Ampere.
9.2.5 Fault memory (Command)
For the analysis and localization of faults the Command version includes a fault memory in which up to
45 fault and alarm messages are saved.
Command
Error store
Æ Settings Æ Device status Æ Error
store Æ Display .
− The last message is at the top.
− Each message line can be marked with
the cursor keys. The message appears in
plain text in the footer.
− Under Source the CAN node is displayed
which signaled the fault.
− Code is the number, which in the Master
is shown in the display until the cause
has been rectified.
− Type: Alarm, Warning or Fault (Error).
T ext Pt 25.70 Tint -8
T ext analog ---.-- Mains U(%) 100.74
T ext serial ---.-- Mains frequ. 50
T cont. head 39.80 Level 4
T heatsink 51.68 Low voltage 27.90
Pump pow. 44.90 5V supply 5.00
Pump rpm 5460 Fan voltage 7.0
Pumpe cur. 1.68 Cur. cons. 2.84
Hel
Menu End T
set
T
fix
No. Source Code Type Date Time
10 Safety 2 Alarm ------------ -----------
9 Safety 4 Warn. 28.08.03 15:32:02
8 Contro. 32 Error 17.07.0310.:52:02
7 Contro. 3 Warn. 06.06.03 11:15:11
6 Contro. 9 Alarm 05.06.03 08:45:01
5 Contro. 3 Alarm 01.06.03 17:58:22
4 Contro. 4 Warn. 28.05.03 20:01:22
3 Contro. 5 Warn. 27.05.03 07:58:00
Low level
Help Menu End T
set
T
fix
