Proline Low-temperature Thermostats
YACE0072 / 21.08.07 Starting up 73
Temp. scale defines how the scaling is to be
carried out:
− automatic , by the program, or
− manual in that you yourself define the
limits with the next menu point.
The min. and max. values for the graphical
display are manually entered with
Temp. limits .
− Temp. min 22.00°C is the momentary
minimum value.
− Temp. max 27.00°C is the momentary
maximum value.
− The highlighted value can in each case be
changed with . Enter the desired new
value in the changes window in the usual
way.
− When setting the minimum value, the
largest permissible value (here 26.90°C,
since the maximum value is 27°C) is
stated.
− When setting the maximum value, it is
conversely the minimum value, which is
entered.
− However, if a value is entered which
exceeds the other corresponding limit,
then this warning is issued:
Warning: Value not in input range .
Hel
Menu Screen T
set
T
fix
6 7 8 9 0
1 2 3 4 5
y-axis Limit:
22.00
Min: -150.00°C Max: 26.90 °C
Hel
Menu End T
set
T
fix
Mode
Displayed value
Legend
Sample Time
Time axis
Time base
Temp. scale
Temp. limits
Temp. min 22.00
Temp. max 27.00
