LAUNCH CreaderV User’s Manual
3.2 Specifications
1) Display: Backlit, 160 x 160 pixels
2) Operating Temperature: 0 to 60°C (32 to 140 F°)
3) Storage Temperature: -20 to 70°C (-4 to 158 F°)
4) Power: 8 to 18 Volts provided via DLC
5) Unit Dimensions: 126 mm × 88 mm × 22 mm (0.80”) （Length×
Width×Thickness）
6) Test Cable length: 0.9m
3.3 Accessories Included
1) User’s Manual -- Instructions on tool operations
2) USB cable--Connect to a computer for upgrading online
3.4 Power supply
The power of the CreaderV is provided via the vehicle Data Link
Connector (DLC). Follow the steps below to power it up:
1) Find DLC on vehicle
A plastic DLC cover may be found for some vehicles and you
need to remove it before plugging the OBDII cable.
2) Plug the connector at the end of OBD II cable to the vehicle’s DLC.
3.5 Tool Setup and self test
Select [Tool Setup] in the Main Menu and press [ ], the screen will
display the interface as shown below:
