Page #21 background image
15 User Manual - LCR Elite2 - ver 1.3
Selecting Secondary Parameters
Table 3-6 describes how to set up secondary parameters from the main menu.
Table 3-6: Set Up Secondary Parameter
Settings
Available Options
Menu Structure
Learn More On:
Secondary Parameters
Rs-Rp, D-Q
Main Menu -> Measurement ->
SEC. PARAM.
Page 10
If resistance mode (Rs-Rp) is selected, the meter shows Rs when circuit mode is selected as series and shows Rp
when circuit mode is selected as parallel. If dissipation or quality factor mode (D-Q) is selected, the meter shows
D when measuring capacitance and shows Q when measuring inductance.
Selecting Test Frequency
Table 3-7 describes how to set up test frequency from the main menu.
Table 3-7: Set Up Test Frequency
Settings
Available Options
Menu Structure
Learn More On:
Test Frequency
Auto, 100Hz, 120Hz,
1kHz, 10kHz
Main Menu -> Test PARAM. ->
Test FREQU.
Page 11
NOTE
The meter is able to use auto frequency to measure capacitance approximately from 3 pF to 199 μF and
inductance approximately from 1uH to 100mH. To measure capacitance or inductance out of this range, please
select proper testing frequency manually according to Table 4-3: Measurement Ranges and Optimal Testing
Frequency.
Selecting Circuit Mode
Table 3-8 describes how to set up circuit mode from the main menu.
Table 3-8: Set Up Circuit Mode
Settings
Available Options
Menu Structure
Learn More On:
Circuit Mode
Auto, Series, Parallel
Main Menu -> Test PARAM. ->
CIRC. Mode
Page 11
If auto mode is selected, series circuit mode or parallel circuit mode will be automatically identified. See Table 3-
9 for the series/parallel rules used.
Table 3-9 Auto Mode Series/Parallel Rules
Range of Component Under Test
Circuit Mode Selected in Auto Mode
C < 400 pF
Parallel Circuit Mode
C >= 400 pF
Series Circuit Mode
L
Always Series Circuit Mode
