LCR Elite2 User Manual

5 User Manual - LCR Elite2 - ver 1.3
The units listed below are applicable to the primary display measurements of the meter.
Table 1-2 Display of Measurement Units
Legend
Description
M
mega 1E+06 (1000000)
K
kilo 1E+03 (1000)
m
milli 1E–03 (0.001)
u
micro 1E–06 (0.000001)
n
nano 1E–09 (0.000000001)
p
pico 1E–12 (0.000000000001)
H
Henry, units for inductance measurement
F
Farad, units for capacitance measurement
Ω
Ohm, units for resistance and impedance measurement
Reset the Meter
The hardware reset function can reset the meter to factory original settings no matter which mode it is currently
in. To perform hardware reset, just press down the navigation button for more than 10 seconds until the display
shows LCR Research logo.
NOTE
After the meter is reset, all the self-calibration data will be removed. Please perform self-calibration again if
necessary.
Cleaning the Meter
WARNING
To avoid electrical shock or damage to the meter, always keep the insides of the casing dry.
Dirt or moisture on the tips can affect measurement accuracy. Follow the steps below to clean the tips and case.
1. Shake out any dirt that may be on the tips.
2. Wipe the tips with a clean swab dipped in alcohol.
3. Wipe the case with a damp cloth and mild detergent.
NOTE
Do not use abrasives or solvents when cleaning the meter.
