20 User Manual - LCR Elite2 - ver 1.3
Capacitance Accuracy Specifications
Table 4-7 LCR Elite2 Capacitance Accuracy Specifications
Range
Resolution
Accuracy = A
C
+ Offset
100Hz
120Hz
1kHz
10kHz
10pF
0.001pF
---
---
---
1.0% + 0.1pF
100pF
0.01pF
---
---
---
0.5% + 0.2pF
1000pF
0.1pF
---
---
0.5% + 0.5pF
0.3% + 0.3pF
10nF
0.001nF
---
---
0.3% + 0.003nF
0.2% + 0.003nF
100nF
0.01nF
---
---
0.2% + 0.03nF
0.3% + 0.03nF
1000nF
0.1nF
---
---
0.2% + 0.3nF
0.5% + 0.3nF
10uF
0.001uF
0.4% + 0.003uF
0.4% + 0.003uF
0.3% + 0.003uF
---
100uF
0.01uF
0.3% + 0.03uF
0.3% + 0.03uF
0.5% + 0.03uF
---
1000uF
0.1uF
0.5% + 0.5uF
0.5% + 0.5uF
0.5% + 0.5uF
---
5mF
0.001mF
0.7% + 0.005mF
0.7% + 0.005mF
---
---
NOTE
The accuracy for the ceramic capacitor will be influenced depending on the dielectric constant (K) of the
material used to make the ceramic capacitor.
