17 User Manual - LCR Elite2 - ver 1.3
Characteristics and Specifications
Product Characteristics
Table 4-1 Product Characteristics
Dimensions (L x W x H)
151 x 19 x 14.5mm
Weight
30 grams
Display
0.91-inch, 128x32 OLED display
Battery
3.7V, 180 mAH internal lithium-ion polymer battery
Battery Life
1 day in typical measurement
(1)
Charging Source
USB port
USB power adapter (output voltage DC 5V ± 5%)
Charging Rate
75mA ± 10%
Charging Time
2.5 hours (typical)
Measurement Speed
1sec (typical)
Operating Environment
Operating temperature from -10°C to 50°C, 0% to 80% RH
Full accuracy up to 80% RH for temperature 23°C ± 3°C
Storage Compliance
-20°C to 60°C, 0% to 80% RH
Safety and EMC
Compliance
FCC15/EN 55011/ICES-003 - Class B, Radiated Emissions
FCC15/ICES-003 - Class B, Conducted Emissions
EN 55011: Mains Terminal Disturbance Voltage, Class B
EN 61000-3-2: Harmonics Current Emissions, Class A
EN 61000-3-3: Voltage Fluctuations and Flicker
EN 61000-4-2: ESD (4 kV Contact, 8 kV Air)
EN 61000-4-3: Electromagnetic Field
EN61000-4-4: Burst
EN61000-4-5: Surge
EN61000-4-6: Conducted RF
EN61000-4-11: Voltage Dips
EN61000-4-11: Short Interruptions
Calibration Cycle
1 Year (Recommended)
NOTE
Battery life varies by use, configuration, and many other factors. Actual results may vary.
