10 Appendix C: Cabling section for speaker lines.
The table below reflects the maximum desirable distance for 100V speaker lines. The type of
cable that is used for the calculations is a two-wire type with copper conductor. The values
shown may be used as a guide for planning, being the responsibility of the installer who will
make the appropriate final calculations for each case.
The table shows the output power of typical amplification channels, constant voltage 100V in
effective watts (rms) are expressed. The maximum length for 70V lines is half of what is
reflected in the table.
Section Maximum length with 5% of loss of power
AWG  mm
mm
2
60Wrms 120Wrms 240Wrms 480Wrms 960Wrms
6 4,11 13,3 3260 1630 810 405 200
7 3,67 10,6 2600 1300 645 320 160
8 3,26 8,35 2050 1025 510 255 130
9 2,91 6,62 1625 810 405 200 100
10 2,59 5,27 1300 645 320 160 80
11 2,3 4,15 1020 510 255 130 65
12 2,05 3,31 810 405 200 100 50
13 1,83 2,63 645 320 160 80 40
14 1,63 2,08 510 255 130 65 35
15 1,45 1,65 405 200 100 50 25
16 1,29 1,31 320 160 80 40 20
17 1,15 1,04 255 130 65 35 15
18 1,02 0,82 200 100 50 25 13
Table 21: Section of cabling for lines of 100V
Caption:
– AWG (American Wire Gauge): American Wire Gauge. Classification according to USA
standard diameters.
–  mm cable diameter in millimeters
mm
2
: Cross-sectional area in square millimeters cable
