Leadshine ES2-DA808 - Connectors and Pin Assignments; Control Signal Connector CN1

DatasheetoftheEasyServoDriveES2‐DA808
LeadshineTe c hnol ogy Co.,Ltd
11/F,BlockA3,iPark,No.1001XueyuanBlvd.Shenzhen,China Tel:1‐949‐608‐7270Fax:1‐949‐608‐7298
Web:www.leadshine.com Email:tech@leadshine.com   
3.1 Control Signal Connector CN1
CN1 – Control Signal Connector
DB44, 44Pin, Female
Pin Name I/O Description
1 NC -
No connection.
2 NC -
No Connection.
MainPowerInput
MotorOutputs
On‐boardHMI
Self‐test,
On‐boardConfiguration
CN3
RS232Configuration
Port
CN1
ControlSignalConnector
Pulse, Direction, Enable Inputs
andFaultOutput
CN2
FeedbackSignalConnector
EncoderConnection
