Operator's Manual
Utilities
Utilities Settings
Utilities settings primarily control the instrument's interaction with other devices/systems. Preferences,
on the other hand, tend to control the appearance and performance of the oscilloscope application.
To access the Utilities dialog, choose Utilities → Utilities Setup... from the menu bar.
HardCopy Setup, Date/Time Setup, and System Status buttons open their corresponding dialogs, as do the
tabs.
There are also tabs linking to Remote Control, Auxilliary Output, and Options settings.
NOTE: Hardcopy Setup controls the behavior of the oscilloscope's Print function. The selected print output
device or application is displayed to the right of the HardCopy Setup button for convenience.
Show Windows Desktop minimizes the oscilloscope application window. Maximize the application by
touching the oscilloscope display icon located at the lower-right of the desktop.
Touch-Screen Calibration launches a sequence of display calibration screens. You will be prompted
through a series of actions to improve the precision and accuracy of the touch screen.
The Service button to the far right of the dialog (not shown) launches a section of the application reserved
for qualified Teledyne LeCroy personnel. An access code is required to enter this section.
922499 Rev B
97
