Operator's Manual
Add Software Option
Many optional software packages are available to extend the Analysis functions of the oscilloscope.See
the product page at teledynelecroy.com for a list of options compatible with your model.
Contact your local Teledyne LeCroy representative or national distributor to purchase an option. You will
receive a Key Code by email that enables the new functionality.
To install the key and activate the software:
1. From the menu bar, choose Utillities > Utilities Setup, then touch the Options tab.
2. Touch Add Key.
The Virtual Keyboard appears onscreen
3. Use the VIrtual Keyboard to type the Key Code in the Enter Option Key field, then touch O.K. on the key-
board to enter the information.
The Key Code is added to the list of Installed Option Keys. You can use the Up/Down buttons to scroll
the list. The software option that each key activates is displayed below the list.
4. Restart the oscilloscope application: choose File > Shutdown, then double-click the Start DSO icon on
the desktop.
922499 Rev B
123
