HDO6000 High Definition Oscilloscope
l To replace a Trigger List setup with the setup on the Trigger dialog, highlight the setup in the
Trigger List and touch the Update Selected button.
l To use a trigger from the Trigger List, highlight its corresponding row on the list, and then touch
the Load Selected button.
l To delete a trigger setup, highlight the setup in the Trigger List and touch the Delete Selected
button.
All trigger setups can be deleted regardless of selections on the Trigger List with one step by touching
the Delete All button.
3. Once you have made the desired changes to the Trigger List, touch the Trainer button and restart the
scan by touching the Start Training button on the Trigger Scan Trainer pop-up. The oscilloscope
automatically cycles through all the trigger setups.
NOTE:
l Use Dwell Time to tune the time that the oscilloscope waits before loading the next trigger.
l If you want TriggerScan to stop when the oscilloscope next triggers, check the Stop On Trigger
checkbox. You can use this to isolate trigger setups.
l If you have Persistence enabled, all trigger events are recorded on the display.
Saving TriggerScan Setups
Save TriggerScan setups whenever you have modified the Trigger List. The current Trigger List is not
preserved after exiting the application unless you manually save it.
1. On the TriggerScan dialog, touch Setup File Name and enter a file name, or touch the Browse button
and select a location and file name.
2. Touch the Save Setup... button.
NOTE: You can load previously saved TriggerScan setups by touching the Browse button, locating the file,
then touching Load Setup....
48
922499 Rev B
