LeCroy WaveSurfer 400 Series

WaveSurfer 400 Series Test Record
Volts
/div.
P S Cpl Measured Channel 1
V & mV
Measured Channel 2
V & mV
Measured Channel 3
V & mV
Measured Channel 4
V & mV
Limits
V
DMM
Mean
1
(A)
∆ 1
Mean−
DMM
DMM
2
Mean
(B)
∆ 2
Mean−
DMM
DMM
3
Mean
(C)
∆ 3
Mean−
DMM
DMM
4
Mean
(D)
∆ 4
Mean−
DMM
mV
2 mV +6m 50Ω ±1.25
5 mV +15m 50Ω ±1.625
10 mV +30m 50Ω ±2.25
.1 V +0.3 50Ω ±13.5
1 V +3.0 50Ω ±126
2 V +6.0 1MΩ ±251
Table 5: Positive DC Accuracy Test Record
Volts
/div.
P S Cpl Measured Channel 1
V & mV
Measured Channel 2
V & mV
Measured Channel 3
V & mV
Measured Channel 4
V & mV
Limits
V
DMM
Mean
1
(A)
∆ 1
Mean−
DMM
DMM
2
Mean
(B)
∆ 2
Mean−
DMM
DMM
3
Mean
(C)
∆ 3
Mean−
DMM
DMM
4
Mean
(D)
∆ 4
Mean−
DMM
mV
2 mV -6m 50Ω ±1.25
5 mV -15m 50Ω ±1.625
10 mV -30m 50Ω ±2.25
.1 V -0.3 50Ω ±13.5
1 V -3.0 50Ω ±126
2 V -6.0 1MΩ ±251
Table 6: Negative DC Accuracy Test Record
Rev D Sept 2007 5 of 10
