In the following table you will find the minimum pulse widths which are required to
release the assigned function at the X4 plug.
Gauger synchronization signal
The function allocations of the inputs 1 up to 3 happen by the
software of the
JET2 neo in the menu Main menu X
You will find a circuit diagram of the interface in the appendix of this
manual!
By the USB-connection you can connect all common USB-devices as e.g. mouse,
keyboard or USB
stick very simply. All data can be exchanged comfortable and
simply by the
connection. Software updates, exchange of variable printing data
or memory expansions can be carried out simply with the USB-stick.
(1)
All 24V inputs marked by (1) are fused by a common self-resetting 700mA fuse.
(2)
When changing the Jobselect inputs, the change must have been made within the bounce
time, i.e. the new Jobselect no. is not detected as valid until the end of this time.
