Leibinger JET2 neo - Filling Reservoir Tanks

Group 5 Transport/Start up Page 37
JET2 neo Release R1.07 en
Installation of print head
During an installation of a device in a production line, the operating
staff should be not endangered. Due to moving products under the
print head danger of bruising and shearing can be caused. The
regulations of the machinery directives should be observed!
5.4 Starting
(Commissioning)
For a safe transport some hydraulic components are supplied with transportation
protection (cable ties) and the reservoir tanks are evacuated. The following steps have
to be carried out before the initial operation
 Remove the transportation protection (cable ties) (Step 1)
 Fill the reservoir tank (Step 2)
 Carry out the function <Fill up routine> (Step 3).
5.4.1 Remove transportation safety devices
(Step 1)
The pumps of the hydraulic system are secured with cable ties. These have to be
absolutely removed.
Proceeding:
 Dismantle the back cover of the hydraulic cabinet (1) by loosing the fixing
screws (2).
Attention!
The cable tie at the main filter (3) should
not be removed!
 Remove the transportation protection (cable ties).

Now attach the back cover of the hydraulic cabinet again with the according
fixing screws.
