Group 6 Operation – Elements and procedures Page 55
JET2 neo Release R1.07 en
6.2.7 Example of use
Figure 14
Example of use
1 – Product
3 – Encoder
5 – Print head
2 – Conveyor belt
4 – Sensor
6.3 Safety instructions
Inflammable (Risk of fire)!
Combustible gases and liquids cause serious burns. Sources of
ignition must be kept away from the print head
and the device!
Risk of injury!
Ink escapes from the head aperture. Spraying of ink into the eyes
can cause blindness. Eye protection is necessary!
3
5
2
1
= Direction of conveyance
4
