13
Leica RM2255
3.3 Technical Data
3. Instrument Components and Specifications
General
Approvals: The instrument-specific marks are located next to the identi-
fication label.
Nominal supply voltages: 100 / 120 / 230 / 240 V AC ±10 %
Nominal frequency: 50/60 Hz
Maximum power consumption 340 VA
Protection class
: I -
according to IEC-1010, UL 3101, EN 61010
Power fuses 2 x T 3.15 A, UL listed
Pollution degree
: 2 -
according to IEC-1010, UL 3101, EN 61010
Overvoltage category
II -
according to IEC-1010, UL 3101, EN 61010
Maximum heat emission: 340 J/s
Operating temperature range: +10 °C to +35 °C
Temperature range during storage: +5 °C to +50 °C
Relative humidity: max. 80 %, non-condensing
Storage humidity: min. 10 % r.H., max. 85 % r.H.
Dimensions and weight
Basic instrument
Width (including handwheel): 413 mm
Width (excluding handwheel): 300 mm
Depth (including waste tray): 563 mm (small) / 618 mm (large)
Height (total): 305 mm (with tray on the hood)
Working height (knife blade): 100 mm (measured from the base plate)
Working height (knife blade): 168 mm (measured from the table)
Weight (without accessories): approx. 37 kg
Control panel
Width: 121 mm
Depth: 166 mm
Height: 50 mm
Height (in inclined position): 81 mm
Weight (net): approx. 0.660 kg
