4. Instrument Setup
4.3 Unpacking and installation
Fig. 9
When the instrument is delivered, check the tilt indicators on the
packaging.
If the arrowhead is blue, the shipment was transported laying flat, was
tilted at too great an angle or fell over during transport.
Note this on the shipping documents and check the shipment for pos-
sible damage.
Fig. 10
1
1
3
4
4
4
4
5
• Remove the packing strap and the ad-
hesive tape (1).
• Remove the carton lid (2).
• Take the accessory carton (optional ac-
cessories) (3) and the cartons (4) from
the standard scope of delivery.
The transport carton and in-
cluded retaining elements
should be kept in case a re-
turn shipment is necessary
later.
2
