6 Technical Data
6.1 General Technical Data of the Product
For details regarding the charging station refer to GKL341 User Manual.
Function Component
Internal storage Exchangeable 256 GB USB 3.0 storage device
235 GB effective, exFAT formatted
Communication Integrated 802.11 a/b/g/n WLAN
The instrument has three integrated HDR digital cameras.
Camera data Value
Type Colour sensor, xed focal length
Single image 4000 × 3000 pixels, 62° × 48° (V × Hz)
Colour depth 8-bits per RGB channel
Full dome 36 images, automatically spatially rectied, 432 Mpx
raw data, 360° × 300°
200 Mpx on point cloud with 3 mm resolution
White balancing Automatic
HDR Automatic, 5 brackets
Minimum range 0.5 m
The RTC360/RTC360 LT is a multi-sensor system equipped with various integ-
rated sensors to allow for automated (RTC360 only) or semi-automated online
registration in the eld.
Sensor Description
Visual inertial sys-
tem VIS (RTC360
only)
Video enhanced inertial measuring system to track
movement of the scanner position relative to the
previous setup in real-time.
Tilt IMU-based.
Accuracy: 3' for any tilt.
Altimeter Electronic barometer to detect the difference in
elevation relative to a reference elevation.
Compass Electronic compass to deliver the orientation of the
instrument.
GNSS Onboard GNSS receiver to calculate the position of
the instrument.
6.2 System Performance
☞
All accuracy specications are on a level of condence of 68%
according to the Guide of the Expression of Uncertainty in Measure-
ment (JCGM100:2008).
☞
Storage and commu-
nication
Internal HDR cameras
Additional internal
sensors
System performance
and accuracy
44 Technical Data
