Leica RTC360 User Manual

Table of Contents
1 Safety Directions 6
1.1 General Introduction 6
1.2 Denition of Use 6
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Laser Classication 12
1.6.1 General 12
1.6.2 Scanning Laser 12
1.7 Electromagnetic Compatibility (EMC) 13
1.8 FCC Statement, Applicable in U.S. 15
1.9 ISED Statements (EN/FR), Applicable in Canada 17
2 Description of the System 18
2.1 Packing / Unpacking the Instrument 18
2.2 Container Contents 18
2.3 Backpack Contents 19
2.4 Instrument Components 19
2.5 System Components 20
2.6 System Concept 20
2.6.1 Power Concept 20
2.6.2 Data Storage Concept 20
3 User Interface 22
3.1 Power Button 22
3.2 Instrument Status 22
3.3 Screen 24
4 Operation 25
4.1 Instrument Setup 25
4.1.1 General Information 25
4.1.2 Lightweight Tripod Setup 25
4.1.3 Heavy Duty Tripod Setup 26
4.1.4 Upside-down Mounting 26
4.2 Power Supply 27
4.2.1 Batteries 27
4.2.2 Exchanging the Batteries 27
4.3 Operation - Getting Started 28
4.4 Imaging 30
4.5 Scanning 30
4.5.1 Ambient Conditions 30
4.5.2 Onboard Controls 31
4.5.3 Settings 34
4.5.4 Troubleshooting 38
4.5.5 Field of View (FoV) 39
4.6 Data Transfer 39
4.7 Working with the USB Data Storage Device 40
5 Care and Transport 41
5.1 Transport 41
5.2 Check & Adjust 41
5.3 Storage 41
5.4 Cleaning and Drying 42
5.5 Glass Cleaning Procedure 42
5.6 Maintenance 43
4 Table of Contents

Leica RTC360 Specifications

General

Scan Rate	up to 2 million points per second
HDR Imaging	yes
Field of View	360° x 300°
Type	3D Laser Scanner
Automatic Targetless Field Registration	yes
Protection Class	IP54
Measurement Range	0.5 – 130 m
Laser Class	Class 1
Laser Wavelength	1550 nm
Scan Time	less than 2 minutes
Camera	Integrated HDR camera
Weight	5.35 kg (11.8 lbs)
