Leica RTC360 User Manual

6 Technical Data 44
6.1 General Technical Data of the Product 44
6.2 System Performance 44
6.3 Laser System Performance 45
6.4 Electrical Data 46
6.4.1 Pin Assignment of Lemo Ports 47
6.5 Environmental Specications 48
6.5.1 RTC360/RTC360 LT 48
6.5.2 GEB361 Battery and GEV282 AC/DC Power Supply 49
6.6 Dimensions 49
6.7 Weight 51
6.8 Accessories 51
6.9 Conformity to National Regulations 51
6.9.1 RTC360/RTC360 LT 51
6.9.2 Dangerous Goods Regulations 52
7 Software Licence Agreement/Warranty 53
Table of Contents 5

Leica RTC360 Specifications

General

Scan Rate	up to 2 million points per second
HDR Imaging	yes
Field of View	360° x 300°
Type	3D Laser Scanner
Automatic Targetless Field Registration	yes
Protection Class	IP54
Measurement Range	0.5 – 130 m
Laser Class	Class 1
Laser Wavelength	1550 nm
Scan Time	less than 2 minutes
Camera	Integrated HDR camera
Weight	5.35 kg (11.8 lbs)
