Traverse TPS1200+/TS30/TM30 237
17.7 Traverse Methods
17.7.1 Starting Traverse
Step-by-step
Step Description
1. PROG. The PROG key opens the TPS1200+/TS30/TM30 Programs
menu.
2. Select Traverse and press CONT (F1).
3. Press CONT (F1) to access TRAVERSE Traverse Information.
)
ENTER to select an existing traverse or to create a new one.
4. CONT (F1) to access TRAVERSE Traverse Configuration.
Check the settings.
5. CONT (F1) to access SETUP Station Setup.
Any standard setup method can be used.
6. SET (F1) to set the station and orientation.
7. If User Guidance is active, a confirmation window is displayed.
FS (F1).
8. TRAVERSE Foresight, Set:X/X
<Foresight ID:> The name of the foresight point.
<Reflector Ht:> The reflector height of the foresight point.
<No. of Sets:> The number of sets to be measured.
9. ALL (F1) to measure and record. The measurement settings for the first
measurement to each point are used for all further sets.
10. TRAVERSE Point Results
CONT (F1) to move to the next station, to return to the TRAVERSE Point
Results screen (and set a point as a closing point), to survey a sideshot,
to view traverse data or to end the traverse.
11. MOVE (F1) to move to the next station. Continue with the next chapter.
