NOVOLAS Basic AT
Interfaces 23
4.3.3 Interface pin assignements X15, including good/bad evaluation
As an alternative, the good/bad evaluation signals may be optained from the digital
output X15 of the CustomerI/O.
The results of the good/bad evaluation of the DataManager are in this case obtained
form the pins X15.4-X15.6. If a new evaluation has been completed, the gauge on
X15.6 will change. The superior unit will then evaluate the signals on X15.4 and X15.5
and complete the welding cycle.
Terminal Description Potential
Trigger-Info
DataManager
X15.1 External digital IO supply and
signal GND, connected to
X14.1
Reference potential
X15.2 Interlock states Bit 7
X15.3 System error or not ready Bit 6
X15.4 Good/Bad Evaluation:
Part not good
Bit 5
X15.5 Good/Bad Evaluation:
Part good
Bit 4
X15.6 Good/Bad Evaluation: New
welding cycle evaluated
Bit 3
X15.7 Laser Unit #A (#C) error or not
ready
Bit 2
X15.8 Laser Unit #A (#C) on Bit 1
X15.9 Laser Unit #A (#C) ready Bit 0
X15.10 External digital IO supply,
connected to X15.10
+24V
